Forever Bright LED Engines

NEW!

FB-8W-CYL-RGBW
2000K-6500K



NEW!

FB-4W-CYL-RGBW
2000K-6500K



NEW! 2200K AMBER!

American made FOREVER BRIGHT LED engines have been completely redesigned to meet the demanding needs of today's designers and installers.

Until now, the choice for LED fixtures has either been to use outdated sockets from the incandescent days and a retro-fit LED bulb, or buy an integrated fixture with the LED components built in. Both of these options have disadvantages. Retro-fit bulbs are not designed for specific fixtures and may not be able to handle wet locations or overheating. Integrated LEDS limit what you can do on job sites to tune up and focus a scene once fixtures have been installed.

Today we introduce our first ever FOREVER BRIGHT HYBRID-MODULE LED, which is neither a light bulb nor an integrated engine. We are now offering in field interchangeable components for all SPJ Lighting LED fixtures.

• IP67 QUICK-CONNECT fitter on all LED modules.
• Twist & Lock cap for interchangeable optic beam spreads.
• Interchangeable wattages from 1 watt- 8 watt.
• Increase wattage over time as needs change.
• Field replaceable.

It has never been easier to fine tune your SPJ lighting systems!

New Innovations! Brighter Light! Higher Efficacy!

We have re-engineered all of our FOREVER BRIGHT LED engines to be even more energy efficient than ever before. Our latest technology has increased brightness (in some cases up to 30% brighter lumen output) while at the same time reducing power consumption. Reducing power means a cooler running LED engine making this year’s SPJ products the most reliable LED’s we have ever manufactured! In addition to improving the electronic components, we have also tuned up our optics. Having better optics in place insures a better light delivery system.





Modular Hybrid Forever Bright Engines
Mr. Universe



FB-8W-CYL-RGBW
2000K-6500K

• Flex-Link
• Precise Full Range Warm Dimming
• Field Changeable



FB-4W-CYL-RGBW
2000K-6500K

• Flex-Link
• Precise Full Range Warm Dimming
• Field Changeable

IP Quick Connect

FB-CYLINDER
FB-1W-CYL-TA16
FB-2W-CYL-TA16
FB-3W-CYL-TA16
FB-6W-CYL-TA16
8-15v
specification download

IP Quick Connect

FB-3W-cone-TA16
*OPTION: DIMMABLE -D
8-15v
specification download

IP Quick Connect

FB-6W-CYL-TA16
FB-8W-CYL-TA16
FB-8W-CYL-TA16-FL

12v-15v

specification download

Interchangeable Optics



Twist and lock cap allows user to change optic beam spread in a snap!

FB-TAB-6W 300 lumens
FB-TAB-8W 580 lumens

Wattage Voltage AC/DC Lumens Color Temp Optics IES Files Download
1W 8-15V 80
96
115
2200K-NEW
2700K
4000K
5000K
Amber
Spot, Flood, Wide Flood, Wide Angle Flood pdf download
2W 8-15V 150
160
170
2200K-NEW
2700K
4000K
5000K
Amber
Spot, Flood, Wide Flood, Wide Angle Flood 2W IES download
pdf download
3W 8-15V
12V Dimmable Option
200
210
220
2200K-NEW
2700K
4000K
5000K
Amber
Spot, Flood, Wide Flood, Wide Angle Flood 3W IES download
pdf download
6W 8-15V
12V Dimmable
Amber
300
320
340
2200K-NEW
2700K
4000K
5000K
Amber
Spot, Flood, Wide Flood, Wide Angle Flood 6W IES download
pdf download
8W 12-15V
Dimmable Option
580
610
700
2200K-NEW
2700K
4000K
5000K
Amber
Spot, Flood, Wide Flood, Wide Angle Flood 8W IES download
pdf download
BB16W
12v-15v, 120v, 277v

(2 FB-8W-CYL-RGBW shown)


specification download
BB24W
12v-15v, 120v, 277v
specification download

BB32W
12v-15v, 120v, 277v
Model Wattage Voltage AC/DC Lumens Color Temp
BB16W
BB24W
BB32W
16W
24W
32W
12-15V, 120V, 277V
12-15V, 120V, 277V
12-15V, 120V, 277V
1160
1740
2320
2700K
2700K
2700K

FB-01CK
Lumens: 125
Wattage: 1.5W
Input Voltage: 8-15V
Color Temp: Amber, 2700K, 4000K

specification download



FB-BB05X
Lumens: 125
Wattage: 2W
Input Voltage: 9-15V
Color Temp: Amber
FB-8W-BRD-RGBW-FL
Lumens: 580
Wattage: 8W
Input Voltage: 9-15V
Color Temp: RGBW 2000K-6500K



FB-RGBW-L5-STRIP
Lumens: 125
Wattage: 2W
Input Voltage: 9-15V
Color Temp: RGBW 2000K-6500K
Model Wattage Lumens
FB-3LS-3" 2W 135
FB-6LS-6" 3W 260
FB-9LS-9" 5W 400
FB-12LS-12" 10W 800

BB0569
Lumens: 800
Wattage: 6W
Input Voltage: 9-15V
Color Temp: Amber, 2700K







Retrofit Lamps

... ...
